Liquid Cooled ATR Chassis For
Exceptionally High Performance.

Staying cool is not easy in many of today’s densely populated embedded computing systems, to get the heat out can sometime call for some liquid refreshment. Tridents rugged liquid cooled ATR chassis offer dual liquid cooled side walls for significantly better cooling. Liquid cooled chassis are used in military and aerospace applications and other high performance applications because they offer excellent heat transfer in ruggedized, light weight package.

Rhino - 3U/6U Liquid Cooled ATR Chassis

Rhino - 3U/6U Liquid Cooled

  • Airborne, shipborne and ground deployment
  • 3U/6U High ATR Chassis with upto 15 Slots Card Area
  • 3U/6U(VPX / cPCI/ VME) Backplane Options
  • Single/dual cooled side walls
  • 1ϕ / 3ϕ AC or 28v DC Input power supply (up to 1500w)
  • Input Transients as per MIL-STD-704E / MIL-STD-1275D
  • EMI/RFI Power Line Filtering
  • No cable Harness
  • MIL-C-38999 type Connectors for power and I/O Signals at rear
  • Option available with ARINC 600 style connectors
  • Hard mount and Custom Design options available

Construction

  • Built with aero grade aluminum
  • Milled Block Construction
  • MIL compliant MIL STD 810F & MIL STD 461E
  • IEEE 1101.20 Mechanical standards
  • Customer defined MIL-Spec painting
